BLISSJUBILE

2130 €

2130 €

2130 €

2130 €

The BLISS Jubilee follows the concept inaugurated by the BLISS Silver, which was the first in its time to benefit from a strict and rigorous matching of all its components. The purpose of this technique is to obtain a perfect similarity of the electrical and mechanical performances of the pair of speakers for a perfectly harmonious musical result.

Learn more

Finition

Noir satiné

Blanc perle

Gris anthracite

Aniegre teinte merisier

Find a distributor Ask your questions

The BLISS Jubilee follows the concept inaugurated by the BLISS Silver, which was the first in its time to benefit from a strict and rigorous matching of all its components. The purpose of this technique is to obtain a perfect similarity of the electrical and mechanical performances of the pair of speakers for a perfectly harmonious musical result.

BLISSJUBILÉ

The BLISS Jubilee is based on a completely new development. The stylistic codes of the Jubilee range can be seen again with large fillets on the rear horizontal edges and rounded edges on the front side that minimize edge effects. Thanks to the use of the golden ratio, the proportions of its cabinetry are more harmonious, it is immediately much more attractive.

Technically sophisticated, it is equipped with the EUTERPE Jubilee drivers: the new 17cm woofer and the excellent 28mm impregnated silk dome tweeter.

Free of any coloration or “box sound” it offers an extremely lively, embodied sound, with a beautiful luminosity without any projection effect or hardness. Its sound image is wide, deep and stable, proof of a careful and very rigorous phasing.

The axial fixing by pressure of its boomer allows to bring back the mechanical reference of the mobile equipment at the back of the enclosure. This principle significantly improves the impulse response of the system. The middle register is more open, more articulate and free of all the artifacts linked to the coupling of the boomer with the supporting baffle.

Its 12db/octave filtering is made by hand with our best components:

-Silver armature capacitors with marked winding direction, they are specifically made for JMR and use JMR HP1132 silver/copper cable terminations.
-Very low resistance air coil using a 1mm deoxygenated pure copper cable.
Non-inductive wound resistors.
-Internal connections entirely made with our JMR HP1132 silver/copper cable.
Wiring “in the air” (components directly soldered to each other without the use of printed circuit boards to minimize insertion losses) hand-assembled on anti-resonant support.

All components are measured, sorted and matched with a tolerance of 1% in order to obtain perfectly identical performance. From then on, the sound image and timbres are perfectly coherent and the phasing is optimal.

In order to optimize its performance in terms of bandwidth and sound image, it should be associated with the Magic Stand II. The long hours of listening necessary to its optimization and thus to validate its development were carried out on these supports.

The BLISS Jubilee will please music lovers who are concerned with a fair sound, without coloration or ostentation, and who desire a frank dynamic, very nuanced, refined and varied timbre. Very easy to feed thanks to its very regular impedance curve never going below 4 Ohms, it offers a very satisfactory performance. You should not hesitate to associate it with high quality electronics in order to obtain very “jubilant” musical performances. They will then easily feed the listening room with a “great sound”, well structured, very homogeneous and with a nice density.

LOADING PRINCIPLE:

It is based on the loading principle developed for the Supreme Offering, a device using 4 coupled cavities with progressive damping leading to a front laminar vent. This proprietary charging principle significantly improves the system’s group propagation time.
Mechanical tensioning of the boomer thanks to a stainless steel threaded rod (non-magnetic) passing through the cabinet from one side to the other, resting on the boomer head and on the bottom of the cabinet. The tension is adjusted with a high-precision torque wrench to ensure the same tightening torque. This axial mounting of the bass driver allows for tensioning of the cabinet walls and ensures evenly distributed mechanical forces between the loudspeaker basket and the supporting baffle, which dramatically improves the transient response of the system.

FILTERING:

Cells at 12dB/octave. Air coils wound with deoxygenated pure copper cable of 1.2mm diameter ensuring a dynamic without settling. Silver armature capacitors sorted in pairs with a tolerance of 1%. Non-inductive coil resistors.
Cut-off frequency 2800 Hz. Wiring “in the air” to reduce insertion loss and using our HP1132 silver cable. The whole filter is assembled on a specific anti-vibration support. It is positioned as far as possible from any magnetic and vibratory disturbance. WBT type terminal block accepting any type of connection (fork, banana or bare cable) on aluminum plate.

HIGH SPEAKERS

BOOMER :

170 mm long fiber paper cone with Gaussian profile, treated on the inside with an extremely effective absorbent material. Flexible and inert polypropylene core cover. It has a 30 mm coil on a ventilated aluminum support, its aluminum frame clears the back of the cone perfectly. Its speeder is also ventilated to allow a better cooling of the coil and thus to lower significantly its distortion rate. It is equipped with a double magnet to increase the concentration of the magnetic flux on the coil. The suspension is made of a rubber-foam compound and has a progressive profile to achieve a very good return force in the extreme low frequencies while preserving the micro-displacements necessary for midrange reproduction.

TWEETER :

The latter is none other than the one proudly displayed by our CANTABILEJUBILE model. A 28 mm impregnated silk dome tweeter particularly powerful. Its directionality is naturally very low, which allowed us to stop using a phase piece. Its linearity is exemplary and its internal damping optimal. It is driven by a powerful neodymium magnet, its very low resonance frequency allows us a cut-off frequency at 2800 Hz in 12 dB/octave. It is fixed with a specific glue to a machined aluminum horn for a better mechanical reference and to further improve its directivity and efficiency.

USE ADVICE:

Thanks to the low directivity, it is not necessary to converge the two speakers to the ideal listening point, but to pinch them very slightly in order to make the most of the system’s phase.

The spacing will be determined experimentally. In theory, the ideal distance is about 2.5m from axis to axis, but this distance can be reduced or increased depending on the acoustic conditions and the dimensions of the listening room. In order to obtain a deep and well-built stereophonic image, make sure that the speakers are at least 40cm away from the side and rear walls.

*The best results in spectral balance and musicality were obtained by using our HP1132 cable, the same one used for the internal connection of all system components.
To optimize its performance in terms of bandwidth and sound image, it should be combined with the Magic Stand II. The long hours of listening necessary to its optimization and thus to validate its development were carried out on these supports.

IMPORTANT :

This system has been developed for home use, in no case it can be used for public or private sound system.
Any incident resulting from such use is not covered by our warranty.

Impedance 4 ohms (minimum)
Frequency response 45hz - 25 khz
Allowable power 80 Watts
Peak power 150 Watts
Power of use 40 to 150 Watts
Sensibility 88 db/W/m (2,83V)
Distorsion less than 0.4% (84db)
Type of filtering 12/12 db/Octave
Connection Single-wire
Dimensions H: 41,6cm - L: 21cm - P: 29cm
Weight 11 Kg
Download the BLISS JUBILEE data sheet
